Cardboard Paper Corrugated Laminating Machine Automatic Flute Pasting Machine

Cardboard Paper Corrugated Laminating Machine Automatic Flute Pasting Machine
Cardboard Paper Corrugated Laminating Machine Automatic Flute Pasting Machine Cardboard Paper Corrugated Laminating Machine Automatic Flute Pasting Machine Cardboard Paper Corrugated Laminating Machine Automatic Flute Pasting Machine

Large Image :  Cardboard Paper Corrugated Laminating Machine Automatic Flute Pasting Machine

Product Details:
Place of Origin: China
Brand Name: JIGUO
Certification: CE, ISO9001
Model Number: FMZ-1200C
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD5000-8000/set
Packaging Details: wooden case
Delivery Time: 50days
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month

Cardboard Paper Corrugated Laminating Machine Automatic Flute Pasting Machine

Description
Max. Sheet Size(mm): 1200x1000mm Min. Sheet Size(mm): 450x450mm
Max. Machine Speed: 105pcs/min(Subject To Paper Quality) Laminating Precision: ±0.5mm(Standard Smooth Paperboard)
Total Weight: 7000kg Machine Dimension: 8900*2470*2180mm
Automatic Grade: Automatic Usage: Paper Board Laminating
Advantage: Easy Control Warranty Of Core Components: 1 Year
Condition: New Core Components: PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear
Application: Food, Beverage, Commodity, Medical, Chemical, Machinery Driven Type: Electric
High Light:

450mm corrugated laminating machine

,

Cardboard Paper corrugated laminating machine

,

Paper automatic flute laminating machine

JIGUO FMZ-1200C Automatic Paper Flute Laminating Machine For Cardboard



Application



Our company specializing in the production of high precision automatic mouunting machine,used for paper jam,gray paper ,coated paper ,such as joint processing,meet the double-sided printing and laminatingmthin and thick paper laminating special processing requirements,such as high precision of framed ,joint before ,suitable for wine box,shoebox,tag,toys,gift boxes,and exquisite packaging products processing.Framed the paper smoothness,High accuracy,high hardness,good characteristics is Our Advantages.


Features


1. Original paper synchronous dynamic calibration system.


2. Adopt double gap design E type, can put into use laminating paper with a pallet truck.


3. Before send paper type suction a top system, size conversion from adjustment, easy to operate.


4. Fluff paper receiver system, can will overlap the finished product, to push again after fluff and tidy. ensure clean paper.


5. Electric adjustment, speed and pressure of paper length conversion is convenient.


6. PLC computer control system, can automatically detect the status of the operation, abnormal situation,maintenance and work record.


7. High precision coating system, automatic liquid level control, can according to adjust the volume.



Cardboard Paper Corrugated Laminating Machine Automatic Flute Pasting Machine 0





Specifications

PARAMETER
Model FMZ-1200C
Max. Sheet Size(mm) 1200*1000mm
Min. Sheet Size(mm) 450*450mm
Thickness of Upper Paper
100-800g/ ㎡
Thickness of Bottom Paper

180-1800g/ ㎡

Max. Machine Speed 150pcs/min(Subject to Paper Quality)
Laminating Precision ±0.5mm(Standard smooth paperboard)
Total Weight 7000kg
Machine Dimension 8900*2470*2180mm
Operation Space 3000*1200mm
Power Supplier 220V/380V 3 ~ (15hp)



Products Description



Cardboard Paper Corrugated Laminating Machine Automatic Flute Pasting Machine 1 1. Feeder system:
Equipped with high speed dedicated feeder,feeding nozzle can freely adjust the angle to the paper;Feeder position adjusts
automatically.



Cardboard Paper Corrugated Laminating Machine Automatic Flute Pasting Machine 2 2. Laminating System:
The paper is chased against the gauge by the speed difference between the paper and the motion gauge, performing high accuracy.



Cardboard Paper Corrugated Laminating Machine Automatic Flute Pasting Machine 3 3.Pressing Conveyor:
Mororized adjusrment of revolving speed and press length allows easy paper size switching.
Press laminated paper in multiple layers,and speed up the revolution with the paper pressed individually.



Cardboard Paper Corrugated Laminating Machine Automatic Flute Pasting Machine 4 4. Electrical system:
Designed in the accordance with European CE stacdard, human-machine interface detects the faults automatically and alarms any abnormal.



Cardboard Paper Corrugated Laminating Machine Automatic Flute Pasting Machine 5

FAQ



Q1: Are you a manufacturer or a trading company?
A: We have our own factory in Tangshan, Hebei Province.



Q2. What is the machine warranty?
A: One year. After the warranty, we still provide technical support to buyer at low cost.



Q3. What is the production time while placing order?
A: Normally about 20-30 days.



Q4. What is the delivery time?
A: 35-50days after deposit.



Q5. Can your company handle shipping for customers?
A: Yes, just give us destination sea port or container yard.



Q6. Does the packing strong?
A: Yes. Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions. A full set of maintenance and operation manuals is included.



Q7. How about the machine installation and training?
A: 1) We provide training in our factory for free; 2) We can send technicians (engineers) to your factory for installation and training. You shall pay round trip air fare and accommodations, plus each technician charges USD100/per day.



Q8. Do you have machines in stock?
A: For standard model, we have a large quantity in stock.For special model,we need 20-30 days to produce for you.



Q9. How can you assure the machines' quality?
A: Each machine will be test running at least 24 hours before delivery to assure the quality. And during the warranty, we will give spare parts for free if machine has any problem.



Q10. Do you inspect machines or test running before packing?
A: Of course we do. We have QC department to debug the machine before packing. If you want to use specific material to do the test running, you need to pay for the cost of the material



Q11. What's the payment term?
A: T/T 30% in advance, the balance shall be paid before delivery. Also accept payment by West Union or L/C at sight.



Q12. Do you accept factory visiting?
A: Warmly welcome for your visiting.



Q13. How many years are you in printing field?
A: JIGUO factory is more than 20years.
