900t Pressure Die Cutting Stripping Machine Cardboard Paper Heating Embossing

900t Pressure Die Cutting Stripping Machine Cardboard Paper Heating Embossing
900t Pressure Die Cutting Stripping Machine Cardboard Paper Heating Embossing 900t Pressure Die Cutting Stripping Machine Cardboard Paper Heating Embossing 900t Pressure Die Cutting Stripping Machine Cardboard Paper Heating Embossing 900t Pressure Die Cutting Stripping Machine Cardboard Paper Heating Embossing

Large Image :  900t Pressure Die Cutting Stripping Machine Cardboard Paper Heating Embossing

Product Details:
Place of Origin: CHINA
Brand Name: JIGUO
Certification: CE
Model Number: MYRP-1060Deep
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $100,000 to $200,000/1 Set
Packaging Details: Wrap film or box
Delivery Time: 45 days
Payment Terms: L/C, T/T
Supply Ability: 50 set

900t Pressure Die Cutting Stripping Machine Cardboard Paper Heating Embossing

Description
Weight: 20T Warranty: 1 Year
After-sales Service Provided: Engineers Available To Service Machinery Overseas,Video Technical Support,Field Installation Dimension(l*w*h): (5100+1450)*(2280+1850)*(2230+670)mm
Type: Die-cutting Machine,Paper Cutting Machine Computerized: Yes
Power(w): 21KW Name: Die Cutting Machine
High Light:

900t Pressure Die Cutting Stripping Machine

,

6500s/h Die Cutting Stripping Machine

,

Heating embossing cardboard paper cutting machine

MYRP-1060Deep Automatic High Speed Die Cutting Stripping Machine With Heating embossing System Heavy Pressure Over 900 Tons


This machine is a professional machine in die-cutting creasing and embossing various PE coated paper, normal paper, corrugating paper and plastic material. It applies to paper cup,paper box,medical package,wine package,food package and other environmental protection products.It adopts micro-computer,HMI,servo positioning,alternating current frequency converter,automatic counting,photoelectric rectifying,pneumatic lock cutting plate,electromagnetic clutch,centralized oil lubrication,,overload protection and distinctive gearing.All of these is the guarantee of steady pressure,precise positioning,smooth running,safety and reliability operation.




Products Description​



    PARAMETER
Model MYRP-1060Deep
Max. sheet size 1070X770(mm)
Min. sheet size 400X360(mm)
Max. die cutting size 1040X750(mm)
Max.cutting speed 6500s/h
Die cutting precision ±0.1mm
Sheet thickness

0.1~4mm

Max.pressure 900T
Total power 62kw
Net weight 20T
Overall dimension 7000 x 4100 x 2420mm
Air requirements 0.8Mpa,>0.36m³/min



1. Automatic vacuum paper, orderly and clean
2. Non-stop delivery gate plate can improve efficiency. When the paper stack is high enough, we can pull out the collect cardboard and push-in another piece deceive paper gate plate to change at the same time, thus achieved the non-stop delivery.
3. Pneumatic sampling, which are accessible at any time to check the die cutting paper, very convenient.



Advantage


* Full automatic creasing carton box die cutting machine.
* T
he machine body casting by special Technology process, thus featuring by high strength, never deformation and ensure the safety of the machine body.
* Adopt Taiwan-imported intermittent mechanism to ensure that the machine operates accurately and reduce the occurrence of failure rate.
* The whole machine all uses SKFNSK imported original bearing.
* The whole machine uses original parts imported from France Schneider, and Japanese OMRON, etc.
* Key parts of teeth row are imported from Japan.
* Die cutting accuracy reach to ±0.1mm .
* The craft shaft is adopts Germany Ni-Cr-Mo metal steel, with high precision and will never deforms.
* Use the centerline positioning system to realize fast plate changing of worksheet.
* Equipped with first-developed pressure automatic adjustment device, ensure fast and smooth when they adjusting of die cutting pressure.
* Die-cutting plate frame adopts auxiliary plate-installation device, to realize different of model machines can be use universal die-cutting plate.
* Equip with touch-screen operation interface in both Chinese and English.
* All adopt Taiwan AIRTAC pneumatic components to ensure every pneumatic action performs accurately.


900t Pressure Die Cutting Stripping Machine Cardboard Paper Heating Embossing 0

900t Pressure Die Cutting Stripping Machine Cardboard Paper Heating Embossing 1



900t Pressure Die Cutting Stripping Machine Cardboard Paper Heating Embossing 2

900t Pressure Die Cutting Stripping Machine Cardboard Paper Heating Embossing 3900t Pressure Die Cutting Stripping Machine Cardboard Paper Heating Embossing 4900t Pressure Die Cutting Stripping Machine Cardboard Paper Heating Embossing 5

FAQ

1.Q:Are you trading company or manufacturer?

A: We are manufacturer, and also provide the business solution to all the friends.

2. Q:What is your delivery time ?

A:Normal delivery time is 30-55working days beside less stock model after received your deposit .

3. Q: Can you help us to buy other goods?

A: Sure of that, it is our honor to work for you, and control the goods quality.

4. Q:How was your machine warranty ?

A:our all machines has one and half year (18mouthes) guarantee. Beside guarantee we will supply

cost spare parts and free maintenance knowledge .

5. Q:How can you do after sales service ?

A:beside the quality guarantee, our company also regards the after sales service, using a full

arrange of service to solve the problems of clients. We supply multiple channels of service by 7x24
hours on phone / on site technical support / on site service / preventive maintenance also training
again.

6. Q:What’s your payment terms ?

A:30% deposit by TT , 70 % balance before shipping by TT or at sight L/C, western union /cash are also

accepted for us .
